Details

Customizable with programming languages, such as Macro and Lua languages, the T405S presents limitless possibilities to aid your weighing operations. With the ability to add additional option cards, the T405S provides everything you need for optimum performance.

Presenting the perfect mix of rugged, versatile, programmable performance, and an affordable price point for all, B-TEK Scales unveils the new T-Series indicators. Designed for industrial applications that require advanced weighing routines and high connectivity.

INDICATOR INPUT: Analog

**Panel Mount Ac Power Adapter (825-250078) is required with Panel Mount Purchase. Available in the "Options and Accessories" Tab**

Specifications

  • NTEP COC: 16-112
  • UL Listed E487985
  • Drive up 16 load cells
  • Freely programmable via LUA and GSE macro scrip
  • Stainless steel (IP69K) enclosure with swivel bracket
  • T405SP stainless (IP66) panel mount enclosure
  • Supports up to 2 scales (with optional input card)
  • 7-digit (0.8”) LCD display w/ 3 line x 6 character graphic array
  • 24-button keypad w/ audible confirmation of press
  • Easy to navigate configuration menus
  • Extensive built-in diagnostic screens
  • Battery backed time/date/year
  • Units: pounds, kilograms, once, gram, lb/oz, custom
  • Scale input digital filtering
  • (2) RS-232 serial port
  • (1) Ethernet: TCP/IP, Ethernet IP, Modbus/TCP
  • (1) USB host: printer, flash memory, keyboard
  • (3) logic level inputs
  • (3) set point outputs, open collector
  • (16) external I/O via optional interface
  • IP Rating: IP69K

IP Rating

  • IP69K
Loading...
Loading Resources ...

Options & Accessories

Loading...
Loading Options & Accessories ...

Frequently Asked Questions

1 - Year Warranty

Industries
